Shop Kaiser Willys

Master Parts List Manual
Fits 55-71 CJ-5 with 4-134 & V6 engines

Part # MANUAL-070

New Reproduction Master Parts List Manual

Reprint of the original master parts list manual. Includes complete vehicle blow up diagrams. Breaks down entire vehicle bolt by bolt in illustrated, numbered pictures. Dont rely on those wrong universal manuals - this is the proper one. Guaranteed. Great suppliment to your mechanics manual.
290 pages.

Egnines:
4-134 engine
6-225 V6 engine

Fits:
55-71 CJ-5

Part # Price
MANUAL-070

$47.99

MSRP:

$47.99

MSRP:

1 Item has been added to your cart!
Close

Questions & Answers

Please Wait...

Ask Question Add Answer

All questions will be displayed after moderation. All answers will be displayed after moderation.

Does it have the wiring diagram for a 71cj5

Willys Jeep Parts Tech:
No, this manual does not cover the wiring schematic. Email mike@kaiserwillys.com

Does this book include diagrams for the factory heater? I have a 1969 CJ5, and the controls utilize vacuum switches and and damper actuators. Are there diagrams showing the vacuum line routing and connection point to manifold (V6 engine)? Thanks!

Willys Jeep Parts Tech:
We will check the manual on the heater portion.

Does this manual have the frame dimensions to locate the motor mounts for a 69 CJ5 with the 4-134 engine? I found frame dimensions online but its specifically says it is for the v6 engine and i don't know if they are different. Thanks.

Willys Jeep Parts Tech:
It does have frame dimensions but it will be more for measuring your frame to make sure its true and not bent.

What is the quality of the diagrams? Can you read the detail?

Willys Jeep Parts Tech:
They are printed here in the USA and the diagrams are readable.

Does this manual contain diagrams of the engine oil lines for running and hooking up the lines?

Willys Jeep Parts Tech:
Yes, it sure does. Thanks
